Electrical Wire Connectors Screw Terminals Easy Twist On Connector
Kit With Spring Insterted Wire Nuts Cap Connections
Screw On Wire Connector
● Material: UL nylon66, with spring inside.
● Color: red/blue/yellow/orange/gray
● Type: Terminal
Features
1) Brand new and high quality
2) Electrical insulation and anticorrosion
3) Lowest aging, lowest fading
4) Long service life
5) Can Withstand 105 Degrees Celsius (221 Degrees Fahrenheit)
6) Cone-Shaped Springs Pull Wires into the Nut Connectors for a
Firm Grip
7) No Need to Pre-Twist Wires
Descriptions
1. Electrical insulation and anticorrosion.
2. Lowest aging, lowest fading.
3. Can Withstand 105 Degrees Celsius (221 Degrees Fahrenheit)
Instructions
1. Strip the two wires.
2. Screw the two wires into one strand.
3. Insert the wires at the same time and tighten them.
| Item No . | Height (mm) | Width (mm) | D (mm) | Suitable Wire |
| P71 | 15 | 9 | 7 | 0.5-1.0mm2 (AWG22-18) |
| P72 | 18 | 10 | 8 | 1.0-1.5mm2 (AWG18-16) |
| P73 | 23 | 11 | 10 | 1.5-2.5mm2 (AWG16-14) |
| P74 | 24 | 14 | 11 | 2.5-4mm2 (AWG14-12) |
| P75 | 28 | 16 | 13 | 4-6mm2 (AWG12-10) |
| P78 | 32 | 18 | 14 | 10-16mm2 (AWG 6) |
Our Advantage:
1, We have our own design team,own mold workshop and injection
moulding workshop.
2, Every new product can be made accurately by your design and
demand.
3,Enough stock to fit your urgently need.
4,Perfect package according to your demand.
Shipping:
1. Please confirm your address carefully once you make the
order.For small quantity, shipment is prefered to shipping with
express by UPS, DHL, EMS, TNT or FedEx to meet your deadline on
time worldwide basis.
2. For regular mass production, shipments can be arranged by
air-shipping, sea-shipping or express. Let us know on your
requirement we will try to save your budget and meet deadline.
Please make sure you read the entire description and agree to the
transaction before buying.
